Vertical platform Multilift
For height differences up to 1.80 meters indoors and outdoors.
For private or commercial applications.
It is designed to be installed with minimal or no structural modifications. The construction of a pit below the lift system is not necessary.
With a ramp, the lift can be installed directly on the ground. The platform lift does not require a machine room and is installed as a complete unit. The drive is mounted on the side.
| Lifting height | Max 1.80 meters |
| Load capacity | 385 kg |
| Drive / Control | Threaded spindle |
| Power supply | 230 V / 16 A |
| Directive / Standards | Machinery Directive 2006/42/EC / EN 81-40 |
Dimensions of the Multilift vertical platform lift
The key dimensions of the Multilift Hublift can be found in the drawing below. It will help you with initial planning and to check if the lift fits into your project. If you have any questions or need further details, we are happy to assist you!
Dimensions of the Multilift Hublift by Garaventa Lift
Mast Height
The mast height of the Multilift Hublift depends on the lifting height. With a maximum lifting height of 1219 mm, the mast height is 2032 mm. At 1829 mm lifting height, it increases to 2642 mm.
Mast height multilift by Garaventa Lift
Technical details
| Drive / Control | Threaded spindle with 1.12 kW motor; Deadman's control |
| Power supply | 230V / 16A |
| Travel speed | 0.04 m / sek. |
| Platform | Platform: 1100 x 1400 mm |
| Load capacity | 385 kg |
| Lifting height | Max 1.80 meter |
| Pit depth | No pit required |
| Call stations | 2 pieces; surface-mounted and flush-mounted solutions |
| Color | RAL 7047 Telegrey |
| Safety | Safety sensors under platform |
| Directive / Standards | Machinery Directive 2006/42/EC / EN 81-40 |
| Options | Automated doors Access control and locking system (Integration of customer’s locking system, EuroKey) Cladding of access doors with acrylic glass |
We have the perfect solution for you.
Contact our specialists for a free consultation.
-
Meet our sales team
We're here to help you find the right lift solution for your needs. Give us a call!
-
Enrico Ghidotti
Sales Manager Switzerland
Contact / Regions:
AI, AR, SG, SH, TG, TI, ZG, ZH
Phone: 041 854 78 23
Mobile: 079 251 42 26
enrico.ghidotti@garaventalift.ch -
Marcel Wicki
Sales Consultant
Contact / Regions:
AG, GL, GR, LU, NW, OW, SZ, UR
Phone: 041 854 78 27
Mobile: 079 373 62 56
marcel.wicki@garaventalift.ch -
Marcel Schulz
Sales Consultant
Contact / Regions:
BE, BL, BS, FR, VS, SO
Phone: 041 854 78 28
Mobile: 079 303 60 03
marcel.schulz@garaventalift.ch
How does a vertical lift work?
Vertical lifts move vertically alongside the stairs, unlike stairlifts that travel along a rail system on the stairs. They resemble elevators, as seen on construction sites. These lifts feature a platform that is well-suited for wheelchair users or individuals with mobility aids. The user controls the lift themselves, retaining control throughout. Upon reaching the destination, the lift stops level with the landing, facilitating easy exit with or without a wheelchair.
Outdoor vertical lift bottom and top
Vertical platform lift indoor, Ticino Canton
Where can a vertical platform lift be installed?
Vertical lifts are very flexible and can be installed indoors or outdoors, often without a shaft. Usually, only minor structural changes are necessary. Due to their compact size, they fit well next to terraces, balconies, or stairs, improving access. They are suitable, for example, for entrance areas with steps or gardens beneath terraces. Share your situation with us, and our staff will find the best solution for you.
Accessibility for everyone
A vertical lift features a platform and is used to vertically overcome small heights up to 1.80 meters. Garaventa Lift's vertical lifts are the ideal stairlift solution for wheelchair users and all individuals who have difficulty navigating different levels due to steps. The lifts are versatile and can be installed both indoors and outdoors without the need for a shaft.
Vertical platform lift outdoor in Baar
Vertical platform lift outdoor for small heights
How much does a vertical lift cost?
The cost of a vertical platform lift depends on many factors, such as the structural situation and individual requirements. Vertical lifts are often a more affordable alternative to platform lifts. For an accurate cost estimate, please contact us directly. We will assess your situation and provide you with a suitable price estimate.
