Primo stairlift with seat
The primo stairlift is ideal for curved stairs and offers you almost limitless possibilities.
The primo stairlift with seat impresses with its limitless possibilities for all types of stairs indoors. It can be mounted on the inside or outside of the staircase and has a space-saving rail layout. Installation is possible over multiple floors. The convenient swivel seat can be rotated onto the landing, allowing for comfortable entry and exit at the top and bottom of the track.
| Rail | Mounted on the inside or outside of the staircase |
| Load capacity | 125 kg |
| Track inclination | 0˚ to 61˚ |
| Application | For straight and curved stairs indoors |
| Drive / Control | Rack-and-pinion drive with deadman's control |
Garaventa Lift Primo stairlift installation
Technical details
| Drive / Control | Rack-and-pinion drive with deadman's control |
| Power supply | 230V charger for 24V battery power supply (socket is sufficient) |
| Travel speed | max. 0.11 m / sec. |
| Seat | Safe and comfortable with seatbelt |
| Rail | Mounted on the inside or outside of the staircase Steel tube with a diameter of 7.6 cm |
| Load capacity | 125 kg |
| Track inclination | 0˚ to 61˚ |
| Call stations | 2 pieces wireless (radio call stations) |
| Colour | Rail: powder-coated in beige, gray, or brown Seat housing: light beige Seat cushion: faux leather cover in beige, burgundy, brown |
| Directive / Standards | Machinery Directive 2006/42/EC / EN 81-40 |
| Options |
There are numerous options to choose from. For the suitable solution, please contact us directly. Automatically folding bottom rail |
Stairlift with swivel seat
This stairlift features an extremely easy-to-use swivel seat (manual or electric) with a pivoting mechanism. The seat surface can effortlessly be rotated onto the landing for safe and comfortable entry and exit at the top of the track or at intermediate stations.
Primo stairlift in a multi-family house
We have the perfect solution for you.
Contact our specialists for a free consultation.
Primo stairlift brochure (only available in German)
(PDF, 1.04 MB)
-
Meet our sales team
We're here to help you find the right lift solution for your needs. Give us a call!
-
Enrico Ghidotti
Sales Manager Switzerland
Contact / Regions:
AI, AR, SG, SH, TG, TI, ZG, ZH
Phone: 041 854 78 23
Mobile: 079 251 42 26
enrico.ghidotti@garaventalift.ch -
Marcel Wicki
Sales Consultant
Contact / Regions:
AG, GL, GR, LU, NW, OW, SZ, UR
Phone: 041 854 78 27
Mobile: 079 373 62 56
marcel.wicki@garaventalift.ch -
Marcel Schulz
Sales Consultant
Contact / Regions:
BE, BL, BS, FR, VS, SO
Phone: 041 854 78 28
Mobile: 079 303 60 03
marcel.schulz@garaventalift.ch
More stairlift solutions for your home
Our stairlifts are specially designed to facilitate access to all floors and allow you to stay in your own home longer. They provide a perfect combination of comfort, safety, and design that seamlessly integrates into your home.
Rigi stairlift
The sturdy yet super-flat rail of the "Rigi" stairlift is the narrowest on the market. This means it takes up less space on your stairs than any other straight stairlift system.
- For straight stairs indoors
- Delivered within a few days
- Wireless call stations (no wiring necessary)
- Grease-free and extremely narrow rail
- Adjustable seat height
Duolex stairlift
The Duolex stairlift, equipped with a robust two-rail system, is characterized by durability and reliability. It is designed to help you safely overcome stairs both indoors and outdoors.
- For straight & curved stairs
- Very narrow & space-saving rail layout
- Maximum load capacity of 160 kg
- Maximum slope angle of 56°
Solaris stairlift
The Solaris stairlift with seat can be delivered and installed ready for operation within one day without the need for measurements; all rail parts are available from stock.
- Delivered the next day
- For straight or curved stairs indoors
- Modular design; no measurements required
- Wireless call stations (no wiring necessary)
- Also suitable for temporary use
