Artira platform lift | outdoor
For convenient outdoor access
Inclined platform lifts are used outdoors to access apartments and houses on sloping terrain. People, luggage, and goods can reach their destination effortlessly.
The Artira offers all the advantages of a modern lift and is the ideal and quick solution for accessing curved as well as straight stairs outdoors. It is cost-effective and low maintenance. Battery operation is deliberately avoided, as reliability is our top priority.
| Drive / Control | Tube - Rope System with Stationary Drive |
| Maximum length | 50 meters |
| Track inclination | 0˚ to 68˚ |
| Load capacity | 250 kg bis 300 kg |
| Regulations / Standards | Machinery Directive 2006/42/EC, EN 81-41:2010 |
Inclined platform lift connects multi-family house outdoor area
Technical details
| Application | For curved stairs indoors and outdoors |
| Installation | On the steps, against the wall, or into the stairwell |
| Load capacity | 250 kg - 300 kg |
| Travel speed | 0.10 / 0.15 m/sec. |
| Power supply | 230 V / 16 A |
| Motor power | 0.95 / 1.5 / 2.2 kW |
| Vehicle | Platforms: 640 x 680, 700 x 750, 800 x 800, 800 x 900, 800 x 1050, 800 x 1220 mm Ramp flaps and safety barriers locked and electrically monitored Safety floor with optical light strips |
| Track inclination | 0˚ to 68˚ |
| Control | It can be stopped at any point by pressing a button on the vehicle or on the call and send buttons on the floors; Smart-Lite technology shows the user which button to press next. |
| Safety Devices | Locked safety barriers, monitored access ramps, safety floor, and safety strips, as well as |
| Directive / Standards | Machinery Directive 2006/42/EC / EN 81-40 |
Elegant, space-saving, and easy operation
The sleek and elegant design of the Artira platform lift sets standards. Unobtrusive and extremely space-saving, the platform lift appears in the parked position. It unfolds fully automatically, moves smoothly, and very quietly. Operation is brilliantly simple. Whether you call the stairlift, send it away, or whether you want to open or close the platform, simply press the button that lights up.
Platform lift enables accessibility in the stadium
We have the perfect solution for you.
Contact our specialists for a free consultation.
-
Meet our sales team
We're here to help you find the right lift solution for your needs. Give us a call!
-
Enrico Ghidotti
Sales Manager Switzerland
Contact / Regions:
AI, AR, SG, SH, TG, TI, ZG, ZH
Phone: 041 854 78 23
Mobile: 079 251 42 26
enrico.ghidotti@garaventalift.ch -
Marcel Wicki
Sales Consultant
Contact / Regions:
AG, GL, GR, LU, NW, OW, SZ, UR
Phone: 041 854 78 27
Mobile: 079 373 62 56
marcel.wicki@garaventalift.ch -
Marcel Schulz
Sales Consultant
Contact / Regions:
BE, BL, BS, FR, VS, SO
Phone: 041 854 78 28
Mobile: 079 303 60 03
marcel.schulz@garaventalift.ch
Weather-resistant platform lift
Our Artira platform lift defies extreme weather conditions. All components are delivered weather-resistant. For this reason, this stairlift is ideal for outdoor use and accessing sloping terrain.
Platform lift with seat
As an option, the platform lift can be equipped with a folding seat, allowing you to comfortably reach your destination while seated.
Installation examples of Artira platform lift
Secure, Slip-Resistant Access in Visperterminen - Thanks to Platform Lift
The Altershilfe Hengert Foundation cares for and supports elderly and needy individuals in collaboration with the Altershilfe Association in Visperterminen. Access to the elderly care and nursing homes for visitors as well as the exit for residents is through interlocking paving stones.
Providing you with the right product for your needs
Contact us for a free consultation tailored to your needs. Additionally, you can book a visit to our showroom - either virtually or in person.
