Artira platform lift | indoor

Name: Garaventa Lift Switzerland
Address: Fännring 2, 6403 Küssnacht am Rigi
Telephone: 041 854 78 80

Solution for simple and complex staircases

The platform stairlift is used in multi-family houses without an elevator or when buildings need to be made accessible for people with disabilities.

Because houses and their entrances are as diverse as their residents. This great variety requires flexible lift solutions, especially when creating barrier-free access retroactively. Our selection of lifts offers an attractive and inconspicuous integration into the living environment. The existing railing is replaced by a unique track and serves as a handrail at the same time. You can't see that a stairlift is installed, but if you need it, it can be called at any time.

Drive / Control	Tube - Rope System with Stationary Drive
Maximum length	50 meters
Track inclination	0˚ to 68˚
Load capacity	250 kg bis 300 kg
Regulations / Standards	Machinery Directive 2006/42/EC, EN 81-41:2010

Plattformlift Artira schliesst sich Inclined platform lift Artira opens and closes

Technical details

Application	For curved stairs indoors and outdoors
Installation	On the steps, against the wall, or into the stairwell
Load capacity	250 kg - 300 kg
Travel speed	0.10 / 0.15 m/sec.
Power supply	230 V / 16 A
Motor power	0.95 / 1.5 / 2.2 kW
Vehicle	Platforms: 640 x 680, 700 x 750, 800 x 800, 800 x 900, 800 x 1050, 800 x 1220 mm Ramp flaps and safety barriers locked and electrically monitored Safety floor with optical light strips
Track inclination	0˚ to 68˚
Control	It can be stopped at any point by pressing a button on the vehicle or on the call and send buttons on the floors; Smart-Lite technology shows the user which button to press next.
Safety Devices	Locked safety barriers, monitored access ramps, safety floor, and safety strips, as well as
Directive / Standards	Machinery Directive 2006/42/EC / EN 81-40

We have the perfect solution for you.

Contact our specialists for a free consultation.

041 854 78 80

info@garaventalift.ch

Inclined platform lift Artira brochure (only available in German)

(PDF, 376 KB)

Technical details + drawings Artira (only available in German)

(PDF, 882 KB)

Meet our sales team

We're here to help you find the right lift solution for your needs. Give us a call!
Enrico Ghidotti

Sales Manager Switzerland

Contact / Regions:
AI, AR, SG, SH, TG, TI, ZG, ZH
Phone: 041 854 78 23
Mobile: 079 251 42 26
enrico.ghidotti@garaventalift.ch
Marcel Wicki

Sales Consultant

Contact / Regions:
AG, GL, GR, LU, NW, OW, SZ, UR
Phone: 041 854 78 27
Mobile: 079 373 62 56
marcel.wicki@garaventalift.ch
Marcel Schulz

Sales Consultant

Contact / Regions:
BE, BL, BS, FR, VS, SO
Phone: 041 854 78 28
Mobile: 079 303 60 03
marcel.schulz@garaventalift.ch

Seamless integration

Our platform lifts not only offer functional versatility but also aesthetically blend seamlessly with your home. With a wide range of color options, you can customize the lift to harmonize with your interior décor

Perfect solutions for tight spaces

Even in narrow staircases, we find a fitting answer thanks to our innovative solutions. An example of this is our compactly designed platform lift, specially developed for narrow spaces. Despite its space-saving construction, it offers safety and comfort and can be seamlessly integrated into almost any staircase situation. This ensures accessibility even in particularly challenging environments.
