The Elvoron H homelift
As a cost-effective alternative to the elevator
The wide range of accessories, doors, mirrors, and colors practically fulfills all customer desires. With the diverse possibilities and options, Garaventa Lift's homelifts can be customized into individually tailored means of transport - simple and elegant.
| Reduced overhead | Min. 2150 mm with hinged doors / 2450 mm with telescopic sliding doors from the upper edge of the top landing level. |
| Pitless elevator | Pit / Recess -130 mm to -150 mm from the upper edge of the finished floor of the bottom landing level is sufficient. |
| Cabin size | Adjustable to fit the floor plan in length and width. |
| Access arrangement | One-sided, opposite, diagonal, or three-sided |
Elvoron H outdoor lift in Immensee, Canton of Schwyz
Technical specifications
| Load capacity | 250 kg - 500 kg |
| Travel speed | 0.15 m/s |
| Lifting height | max 14.5 m |
| Power supply | 400 V |
| Number of stops | max 8 |
| Cabin entrances | max 3 |
| Same-side floor-to-floor distance | min 2230 mm |
| Opposite-side floor-to-floor distance | min 350 mm |
| Control system | Impulse or constant pressure control |
| Door opening and closing | Semi- or fully automated |
| Cabin height | 2100 mm (min. 2000 mm - max. 2200 mm) |
| Door height | 2000 mm (min. 1800 mm - max. 2100 mm) |
| Cabin width | min 600 mm - max 1400 mm |
| Cabin depth | min 600 mm - max 2000 mm |
| Door width | min 500 mm - max 1000 mm |
| Control cabinet | Width 770 mm / Depth 560 mm / Height 1650 mm |
| Shaft headroom | min 2150 mm / 2450 mm (Telescopic sliding doors) |
| Pit depth | min 130 mm |
| Emergency control | Automatic user evacuation in case of power failure |
| Emergency call installation | Integrated telephone with gateway via mobile network or automatically dialing and functionally monitored emergency call system |
Space-saving Hydraulic Lift
As a hydraulic lift system, the Elvoron H does not require a pit or a machine room. Instead, the machine and control panel are installed either in the existing utility room of the building or in a separate machine cabinet away from the lift. This ensures that the distinctive appearance remains unaffected, and the lift operation is particularly quiet.
Comparison between hydraulic lift system and roped elevator
We have the perfect solution for you.
Contact our specialists for a free consultation.
Elvoron H brochure (only available in German)
(PDF, 1.45 MB)
Technical Details Elvoron H (only available in German)
(PDF, 921 KB)
-
Meet our sales team
We're here to help you find the right lift solution for your needs. Give us a call!
-
Enrico Ghidotti
Sales Manager Switzerland
Contact / Regions:
AI, AR, SG, SH, TG, TI, ZG, ZH
Phone: 041 854 78 23
Mobile: 079 251 42 26
enrico.ghidotti@garaventalift.ch -
Marcel Wicki
Sales Consultant
Contact / Regions:
AG, GL, GR, LU, NW, OW, SZ, UR
Phone: 041 854 78 27
Mobile: 079 373 62 56
marcel.wicki@garaventalift.ch -
Marcel Schulz
Sales Consultant
Contact / Regions:
BE, BL, BS, FR, VS, SO
Phone: 041 854 78 28
Mobile: 079 303 60 03
marcel.schulz@garaventalift.ch
The customized lift solution
The Elvoron H lift can be easily integrated thanks to its small installation dimensions and modular system design. This lift can be installed with a modular shaft inside the building or outdoors, as well as in a lift shaft constructed on-site.
Elvoron H outdoor installation without an on-site shaft at a multi-family house
Elvoron H indoors - Multi-family house
Comfort, security, and added value for private homes
For owners of private properties, comfort and future planning for aging are important criteria. By providing a customized lift solution tailored to the property's requirements, this desire can be fulfilled. The Elvoron H lift combines modern, elegant aesthetics, reliability, and low operating and maintenance costs.
Barrier-free access solution for all areas
Barrier-free construction is now a standard requirement. Especially in existing properties, retrofitting a lift can be difficult and costly. The Elvoron H lift can be easily integrated due to its compact installation dimensions. Thanks to minimal structural modifications, cost-effective lift solutions can be realized even in heritage-listed buildings.
Outdoor view of Elvoron H barrier-free
A versatile and intelligent lift concept
The special construction allows for countless configuration options. Compact installation dimensions without pit or overhead enable cost-effective integration with minimal on-site adjustments. The Elvoron H lift can be installed in an on-site or existing lift shaft, as well as delivered complete with a modular shaft in steel construction with laminated safety glass or metal panels.
Installation examples of Elvoron H
